FX 3360 PortAir
FX 3360 PortAir
Portable Air Permeability
and ThicknessTester
Demo Video:
Continuously measures the air permeability or the pressure drop, respectively, and/or the thickness of fabrics, non-wovens, felts, films and paper maker cloth. The instrument for measurements at the moving web directly in the production machine.
Special Features
-
Wide measuring range. AP: approx. 0.2-1,000 ft³/ft²/min (approx. 1-5,000 l/m²/s), thickness: 0-6 mm.
-
The instrument is suitable for both, spot and profile measurements.
-
High measuring accuracy
-
High measuring speed of up to 200 m/min. (!)
-
High resolution of up to 1 mm test point pitch.
-
Light weight portable instrument, suitable for one-handed operation, even overhead.
-
Touch screen display for digital and graphic display of the test results.
-
Worldwide only instrument of this kind.
-
Works in accordance with all major test standards.
-
Calibratable.
Parameters
Air Permeability :
Measuring range :
Measuring accuracy：
Test pressure：
Test area：
Units of measure：
approx.1 through 5,000mm/s (0.2 through 1,000cfm)
± 3 % of the displayed value
98 through 500Pa
20 cm²
Cfm，cm³/cm²/s，mm/s，l/m²/s，l/dm²/min，m³/m² /s， m³/m²/min，m³/m²/h
Pressure drop：
Measuring range：
Measuring accuracy：
Air Velocity :
Test area：
approx. 0.01 through 65000 Pa
± 3 % of the displayed value
0.001 through 10 m/s (0.2 – 2000 ft/min)
20 cm²
Thickness：
Measuring range：
Measuring accuracy：
Units of measure：
Clamping Pressure：
Test Area：
0 through 6mm
±0.02mm ±0.5% of the displayed value
mm，μm，mil
1 through 20N
1，2，3，10，20 or 25 cm²
General technical specification：
Test point pitch：
Maximum measuring speed：
Data port：
Average battery life-time：
power requirements：
1 through 100mm (0.04 through 4”)
200m/min at 100mm test point pitch
USB1.1
approx. 120min
90 through 264V，50 through 60Hz，60W
Dimensions/ weights：
Instrument :
Instrument with transportations case :
Instrument with case, packed for shipping :
42 x 21 x 16cm/ 4.8kg
55 x 43 x 21cm/ 10.7kg
61 x 51 x 28cm/ 12.5kg
Operating temperature range：
0 °C through 45 °C
Storage temperature range：
-20 °C through 60 °C
