FX 3340 MinAir
FX 3340 MinAir
Mobile Air Permeability Tester
Demo Video:
Measures the air permeability and pressure drop of all types of flat materials in the laboratory and in the field.z.
Special Features
-
Compact, lightweight design
-
Portable instrument, perfectly suited for mobile use
-
Optional rechargeable battery
-
Automatic test pressure control
-
Fast and simple sample clamping
-
Optional PC Evaluation Software
Parameters
Measuring range (Air Permeability) :
60 – 6,000 mm/s (12 – 1,200 ft³/ft²/min) at 5 cm²15 – 1,500 mm/s (3 – 300 ft³/ft²/min) at 20 cm²
Test pressure：
20 – 500 Pa
Measuring range (Pressure drop) :
Air Velocity :
Test areas：
20 – 500 Pa
0.060 – 6.0 m/s (12 – 1,200 ft/min) at 5 cm²0.015 – 1.5 m/s (3 – 300 ft/min) at 20 cm²
5 and 20 cm²(20cm² included, 5cm² optional)
Units of measure :
Measurement Accuracy :
mm/s, l/m²/s, l/dm²/min, cm³/cm²/s, ft³/ft²/min, m³/m²/s,m3/m²/min, m³/m²/h 和 Pa (pressure drop)
± 3 % of the displayed value
Projection Clamping Arm：
160 mm
Sample Thickness :
Max. 8 mm
Data ports：
Power requirements：
USB 2.0
100 – 240 VAC, 50 – 60 Hz, 100 W
Dimension (W x D x H)：
16 x 34 x 25 cm
Net Weight :
4.9 kg
Test Standards
-
ASTM D 737
-
BS 5’636
-
DIN 53887
-
EDANA 140.1
-
EN ISO 9’237
-
EN 14683, Annex C
-
WSP 70.1
